Technical Specification

Model: BonSensor

Mechanical Dimensions (mm³): 25.0 × 38.5 × 4.5
Active Area (mm²): 20 × 30
Pixel Matrix: 1000 × 1500
Theoretical Resolution: 25 lp/mm
Sensor Technology: APS CMOS
Scintillator: Directly deposited CsI
Cable Length: Standard 3 m / Optional 5 m
Gray Level: 16 bits
Exposure Mode: Smart AED
Protection: IP68
TWAIN Protocol Support: Yes
Required Operating System: Windows 7 or newer, 32/64 bit
